Dragonfly-WSN

Wireless IoT system for air conditions monitoring


About
Dragonfly-WSN is a wireless environment control system. It easily helps to measure realtime parameters of air temperature, relative humidity and atmospheric pressure in different types of rooms
Easy installation
Wireless communication at a distance of up to 1 km significantly reduces the cost of installation and commissioning. Installation savings compared to wired systems - up to 40-60%.
Modularity
"Three-in-one" sensors measure air temperature, relative humidity and atmospheric pressure. The capabilities of the system are expanded by external sensing elements, like VOC, Co2 and light sensors. The system can be used on moving objects (for example, refrigerated vehicles).
Realtime remote control
"Dragonfly-WSN" can be used as an independent system or part of an enterprise industrial control system. Remote access allows the system to be updated through the air. The system can be used as a "radio extension" for traditional wired industrial interfaces, like RS-485.

Sensors

Sensor
«Dragonfly» sensor
• Power by 1хААА battery
• Up to 1 year battery life
• Replaceable sensing element
• IP31 protection level. Optional - IP55
• Connection of external sensing elements
Gateway
«868» gateway
• 868 MHz
• USB or RS485 connection
• Works on Modbus-RTU protocol
• Up to 50 sensors connection
• Up to 1 km communication distance
Features
Value
Range
Accuracy
Temperature
-20..+75°С
±0.5°С at 5°С<T<50°С
Relative humidity
0..100%
±2% at 20%<RH<70%
Atmospheric pressure
700..1100 GPa
±1 ГПа at 5°С<T<50°С
Used in
  • Factories
    Factories
    Compliance with production standards
  • Labs
    Labs
    Clean rooms
  • Retail
    Retail
    Compliance with storage standards
  • Rooms and buildings
    Rooms and buildings
    as part of HVAC
  • Data Centers
    Data Centers
    Temperature control
  • Warehouses
    Warehouses
    Validation for GMP standards
Pricing
Send your request and our sales specialists will contact you for more details.
